PCC-Rule-Status AVP

Description of AVP

AVP

Description

PCC-Rule-Status

The PCC-Rule-Status AVP (AVP code 1019) is of type Enumerated, and describes the status of one or a group of PCC Rules.

The following values are defined for the PCC-Rule-Status AVP:

  • ACTIVE(0)

    The value indicates that the PCC rules are successfully installed (for those provided by the PCRF) or activated (for those pre-defined in PCEF).

  • INACTIVE(1)

    The value indicates hat the PCC rules are removed (for those provided by the PCRF) or deactivated (for those pre-defined in PCEF).

  • TEMPORARILYINACTIVE(2)

    The value indicates that installed or activated PCC rules are temporarily disabled for some reason (for example, loss of bearer).

Reference Standards

3GPP TS 29.212 V9.7.0 clause 5.3.19
