DC Power Cable (Quick-Connect Cord End Terminal)
Appearance and Structure
DC power cables consist of the power cable for a 350 W/650 W DC power module and the power cable for a 1000 W DC power module.
Figure 1 shows the appearance of the power cable for a 350 W/650 W DC power module.
Figure 2 shows the structure of the power cable for a 350 W/650 W DC power module.
Figure 3 shows the appearance of the power cable for a 1000 W DC power module.
Figure 4 shows the structure of the power cable for a 1000 W DC power module.
Pin Assignments
Table 1 lists the pin assignments of the power cable for a 350 W/650 W DC power module.
X1 |
X2 |
X3 |
Length |
Conductor Cross-Sectional Area |
|---|---|---|---|---|
2 female |
Cord end terminal 4^2 grey |
Cord end terminal 4^2 grey |
3 m |
3.332 mm2 (12AWG) |
Table 2 lists the pin assignments of the power cable for a 1000 W DC power module.
Connection
A DC power cable connects to the DC power module of the device:
- X1 connector connects to the input port on the DC power module.
- X2/X3 cord end terminal connects to an external power module.
